24V Mini Compressor
Eco-friendly direct current mini compressor comes with great power and less noise.
- 24V DC
- R134a Refrigerant
- Brushless Motor Drive
- Small in size, yet large in power density
- 2,000~6,000 rpm variable speeds drive board
- The world’s smallest footprint 24V DC compressor
- Small Compressor for Heating and Cooling (HBP/MBP/LBP)
RIGID: Your Premier 24V Compressor Supplier
RIGID 24V DC compressor is bldc rotary compressor using refrigerant R134a.The 24V Compressor is powered by direct current (DC) electrical energy. Its tiny size is perfect for micro and mobile cooing system and air conditioning applications.
24 Volt compressor is controlled by our developed patented driver board, which has the function of variable speed ranges from 2000rpm to 6000rpm.
With a wide range of application of air conditioning and refrigerating conditions, our 24V compressor has features of exceptionally compact and outstanding cooling capacity, which enable it applies to mobile and compact cooling systems.
Plus, the 24V direct current compressor is the best mini compressor has outstanding performance than that of Peltier cooling. Furthermore, 24V compressor has lower working current than that of 12V compressor.
RIGID 24V dc compressor has the world’s smallest size and lightest weight. It is ideally suited to meet the stringent demands of mobile and portable cooling.
Through our line of miniature compressors, RIGID provides the key enabling technology to original equipment manufacturers for small and portable systems that were not previously possible.
Our 24V DC compressor is equipped with the brushless motor, well matched with our patent driver board. Thus, it is able to fully motivates Rigid dc compressor’s performance.
Technical Data
24V Compressor Specification Download:
- 24V R134a QX1902VDL(H)
- 24V R290 QX2802VDL-T
- 24V R134a QX2802VDL
- 24V R290 QX3802VDL-T
- 24V R134a QX3802VDL
- 24V R134a XB075Z-24
- 24V R134a KVB150Z-24
Other Documents Download:
Certificate – TÜV Rheinland – EMC Service – Miniature Compressors
Compressor Model
24V MINI COMPRESSOR
Model: QX1902VDL(H)
- Voltage: 24V DC
- Refrigerant: R134a
- Net Weight: 1.6 lbs / 0.72kgs
- Motor Type: Variable Speed Motor
- Cooling Capacity: 100~455W (360~1550Btu)
- Applications: Heating, Cooling and Refrigeration
24V MINI COMPRESSOR
Model: QX2802VDL
- Voltage: 24V
- Weight:1.3kgs /2.87lbs
- Refrigerant: R134a
- Cylinder Number: 2 pumps
- Size: 117.5 x 61 mm (High x Diameter)
- Capacity: ≥490W (1,670Btu)
- Working Amps: 1~8.3A, (Maximum 12A)
- Variable speed drive board (1,800~4,500rpm)Display Panel included
- Work at ambient temperature -20℃ ~ 55℃
- Applications: Miniature Refrigeration & Freezer System; Portable Cooling System.
24V R290 MINI COMPRESSOR
Model: QX2802VDL-T
- Voltage: 24V
- Weight:1.3kgs /2.87lbs
- Refrigerant: R290
- Cylinder Number: 2 pumps
- Size: 117.5 x 61 mm (High x Diameter)
- Capacity: ≥500W to 700W (2,387Btu)
- Working Amps: 1~8.3A, (Maximum 12A)
- Variable speed drive board (2,100~4,500rpm)Display Panel included
- Work at ambient temperature -20℃ ~ 55℃
- Applications: Miniature Refrigeration & Freezer System; Portable Cooling System.
24V MINI COMPRESSOR
Model: QX3802VDL
- Voltage: 24V
- Weight:1.6kgs /53lbs
- Refrigerant: R134a
- Cylinder Number: 2 pumps
- Capacity: ≥635W (2,165Btu)
- Size: 152.6 x 61 mm (High x Diameter)
- Working Amps: 1~12A
- Variable speed drive board (2,100~4,500rpm)Display Panel included
- Work at ambient temperature -20℃ ~ 55℃
- Applications: Miniature Refrigeration & Freezer System; Portable Cooling System.
24V R290 MINI COMPRESSOR
Model: QX3802VDL-T
- Voltage: 24V
- Weight:1.6kgs /53lbs
- Refrigerant: R290
- Cylinder Number: 2 pumps
- Capacity: ＞760W (2,592Btu)
- Size: 152.6 x 61 mm (High x Diameter)
- Working Amps: 1~12A
- Variable speed drive board (2,100~4,500rpm)Display Panel included
- Work at ambient temperature -20℃ ~ 55℃
- Applications: Miniature Refrigeration & Freezer System; Portable Cooling System.
24V LARGE COMPRESSOR
Model: XB075Z-24
- Voltage: 24V DC
- Refrigerant: R134a
- Net Weight: 17.2 lbs / 7.8kgs
- Motor Type: Variable Speed Motor
- Cooling Capacity: 850W (2,898Btu)
- Applications: Heating, Cooling, and Refrigeration
24V LARGE COMPRESSOR
Model: KVB150Z-24
- Compressor Series: KVB150
- Refrigerant: R134a
- Running Voltage: 24V
- 2000-4500rpm with drive board
- Input Power: 600W
- Cooling Capacity: 1780W (6,069Btu)
- High power mini compressor for truck/RV DC air conditioner/battery cooling/laser cooling etc.
Advantage
High Capacity
High Efficiency
High Reliability
Miniature Size
Low Weight
Low noise
Application
Features
High Performance By BLDC Motor
RIGID direct current 12V mini compressor comes with a sine wave variable speed driver board, delivering efficient and reliable performance.
DC Inverter By RIGID Technology
Wide-range inverter compressors satisfy your innovative demands and design. Your product will stand out, your compressor will go unnoticed.
360° Sine Wave Inverter Drive Board
RIGID inverter compressor drive board has features of high reliability and power density. It has automatic dual-protections to the compressor.
Mini Compressor Projects
Medical Device
Laser CO2
3D Printer
Vertical Farming
Racing Cooler
Telecommunications Cabinet
FAQs
1. What's 24V mini compressor?
RIGID 24V mini compressor is a key component of refrigeration and air conditioning applications. Compressors are the “heart” of such appliances, comparable to a car engine or even the human heart. A compressor is a mechanical device that increases the pressure of a gas by reducing its volume.
RIGID Technologies presents the lightest, most compact, and more efficient BLDC Inverter Rotary Compressor.
2. What are RIGID 24 volt mini compressor applications?
RIGID 24V mini compressors are designed for small and portable Air Conditioning and Freezing applications.
- Water Dispenser
- Beverage Cooling
- Portable Air Conditioner
- Portable Cooling Systems
- Mini-Chilled Water Systems
- Telecom Equipment Cooling
- Electronics Cooling Systems
- Medical-Aesthetic Device Cooling
- Miniature Refrigeration/Freezer Systems
- Thermally-Controlled Shipping Containers
3. What's RIGID 24V mini compressor features?
- Super small volume: 56.5 x 78 mm (LxH)
- Super lightweight: 720g (1.6lbs)
- Use a brushless motor, 24 volt DC.
- Variable speed drive board included.
- Low vibration with anti-vibration cushions
- High-temperature working conditions can work under 52C-degree ambient temperatures.
4. Where can I buy 24 volt mini compressor online?
Purchase from our online store
- Mini Compressor QX1902VDL (450W)
- Mini Compressor QX3202VDL (550W)
- Mini Compressor QX2002VDL (≥325W to 525W)
- Twin Cylinder Compressor QX2802VDL (550W)
- Twin Cylinder Compressor QX2802VDL-T (≥500W, R290)
Your order will be proceeded in 12hrs and delivered by DHL/UPS/FedEx Express.
5. What freon does RIGID 24V mini compressor choose?
RIGID 24V mini compressor chooses refrigerant R134a or R290 or R1234yf
Plus, RIGID has other compressors choose R290, R1234yf, R410A, and R600A. For more dc compressors, feel free to visit the page – MINI COMPRESSOR.
6. What's the type of RIGID 24V mini compressor?
All RIGID compressors, including the 24V mini compressor, are Vapor-compression refrigeration rotary compressors.
7. What do Vapor-compression refrigeration compressors do?
The Vapor Compression Refrigeration Cycle.
As the refrigerant circulates through the system, it is alternately compressed and expanded, changing its state from a liquid to a vapor. As the refrigerant changes state, heat is absorbed and expelled by the system, lowering the temperature of the conditioned space.
8. Can I use the 24V mini compressor for portable DC air conditioner?
Sure, you can. RIGID 24-volt mini dc compressor is widely used in small portable dc air conditioners like campers and outdoor camping. It is the best choice for your custom design too.
Your product will stand out, your compressor will go unnoticed.
9. What are RIGID 24V mini compressor advantages?
Only 1/17th of the volume, 1/11th of the weight than the conventional compressor. While cooling capacity and efficiency are Twice more than the reciprocating compressor.
Just imagine what you can do with our ultra-compact, yet powerful and highly efficient rotary dc compressor to drastically improve your small applications and equipment!
10. Can I use RIGID 24V mini compressor in vapor HVAC system?
Absolutely!
RIGID 24-volt Vapor-compression compressor uses a circulating liquid refrigerant as the medium which absorbs and removes heat from the space to be cooled and subsequently rejects that heat elsewhere.
Features:
- Ultra-small footprints.
- Various Speed ranges of 2,000~6,500rpm.
- Charged by Battery, Solar Power & Car Power.
